- High-Quality Material: The product is made of high-quality malleable cast iron material that is both tough and durable. It can withstand high pressure and high-temperature environments, exhibits excellent corrosion resistance, and has a long service life.
- Excellent Craftsmanship: The product is manufactured using exquisite craftsmanship to ensure its precision and quality. The surface is smooth, free from defects such as pores, inclusions, and cracks, which guarantees the product's sealing performance and service life.
- Multiple Specifications: The product is available in multiple specifications, suitable for connecting pipes with different diameters. Moreover, it has a wide range of models and specifications to meet different customer needs.
- Convenient and Easy to Install: The product is easy to install and does not require professional skills or tools. It uses a threaded connection, which saves installation time and costs.
- High Reliability: The product offers a tight and secure connection with excellent sealing and reliability, preventing leaks and spills and ensuring normal pipeline operation.
Category150 Class BS / EN standard Beaded Malleable cast iron pipe fittings
Certificate: UL Listed / FM Approved
Surface: Black iron / hot dip galvanized
End: Beaded
Brand: P and OEM is acceptable
Standard: ISO49/ EN 10242, symbol C
Material: BS EN 1562, EN-GJMB-350-10
Thread: BSPT / NPT
W. pressure: 20 ~ 25 bar, ≤PN25
Tensile Strength: 300 MPA(Minimum)
Elongation:6% Minimum
Zinc Coating: Average 70 um, each fitting ≥63 um
Available Size:
| Item |
Size |
Weight |
| Number |
(Inch) |
KG |
| ERS0705 |
3/4 X 1/2 |
0.09 |
| ERS1005 |
1 X 1/2 |
0.135 |
| ERS1007 |
1 X 3/4 |
0.143 |
| ERS1205 |
1-1/4 X 1/2 |
0.197 |
| ERS1207 |
1-1/4 X 3/4 |
0.201 |
| ERS1210 |
1-1/4 X 1 |
0.21 |
| ERS1505 |
1-1/2 X 1/2 |
0.273 |
| ERS1507 |
1-1/2 X 3/4 |
0.245 |
| ERS1510 |
1-1/2 X 1 |
0.266 |
| ERS1512 |
1-1/2 X 1-1/4 |
0.288 |
1.Heavy molds and competitive prices
2.Having accumulating Experience on producing and exporting since 1990s
3.Efficient Service: Replying a Inquiry within 4 hours, fast delivery.
4. Third party certificate, such as UL and FM, SGS.
Keep every pipe fitting that our Clients’ received is qualified.
Q:Are you factory or trading company?
A:We are factory with +30 years history in casting field.
Q: What terms of payment do you support?
A: TTor L/C. 30% payment in advance, and the 70%balance would be
paid before shipment.
Q: How long is your delivery time?
A: 35 days upon receipt of advanced payment.
Q: lt is possible to get samples from your factory?
A: Yes. free samples will be provided.
Q: How many years the products guaranteed?
A: Minimum 1 years.
