Category150 Class BS / EN standard Beaded Malleable cast iron pipe fittings
- Certificate: UL Listed / FM Approved
- Surface: Black iron / hot dip galvanized
- End: Beaded
- Brand: P and OEM is acceptable
- Standard: ISO49/ EN 10242, symbol C
- Material: BS EN 1562, EN-GJMB-350-10
- Thread: BSPT / NPT
- W. pressure: 20 ~ 25 bar, ≤PN25
- Tensile Strength: 300 MPA(Minimum)
- Elongation:6% Minimum
- Zinc Coating: Average 70 um, each fitting ≥63 um
Available Size:
| Item |
Size |
Weight |
| Number |
(Inch) |
KG |
| EP05 |
1/2 |
0.043 |
| EP07 |
3/4 |
0,.078 |
| EP10 |
1 |
0.118 |
| EP12 |
1.1/4 |
0.188 |
| EP15 |
1.1/2 |
0.207 |
| EP20 |
2 |
0.379 |
1.Heavy molds and competitive prices
2.Having accumulating Experience on producing and exporting since 1990s
3.Efficient Service: Replying a Inquiry within 4 hours, fast delivery.
4. Third party certificate, such as UL and FM, SGS.
Keep every pipe fitting that our Clients’ received is qualified.
1.Q: Are you factory or trading company?
A: We are factory with +30 years history in casting field.
2.Q: What terms of payment do you support?
A: TTor L/C. 30% payment in advance, and the 70%balance would be paid before shipment.
3.Q: How long is your delivery time?
A: 35 days upon receipt of advanced payment.
4.Q: Your Package?
A.Exporting Standard. 5-layer Master Cartons with inner boxes, Generally 48 Cartons packed in on pallet, and 20 pallets loaded in 1 x 20”container.
5. Q: lt is possible to get samples from your factory?
A: Yes. free samples will be provided.
6. Q: How many years the products guaranteed?
A: Minimum 1 years.
Some widely used pipe fitting standards are as follows:
ASTM International: American Society for Testing and Materials
This is one of the largest voluntary standards development organizations in the world. It was originally known as the American Society for Testing and Materials (ASTM). This is a reputed scientific and technical organization that develops and publishes voluntary standards on the basis of materials, products, systems and services. This is a trusted name for standards. The standards covered by this organization covers various types of pipes, tubes and fittings, especially made of metal, for high-temperature service, ordinary use and special applications like fire protection. The ASTM standards are published in 16 sections consisting of 67 volumes.
