Item |
Size (inch) |
Dimensions |
Case Qty |
Special Case |
Weight |
|||||||||||||||||
|
Number |
|
|
A |
|
B | C |
Master |
Inner |
Master |
Inner |
(Gram) |
|||||||||||
| PLG01 | 1/8 | 0.27 | 0.28 | 0.24 |
1400 |
5/bag |
|
1400 |
5/bag |
8.8 |
||||||||||||
| PLG02 | 1/4 | 0.41 | 0.37 | 0.28 |
1200 |
5/bag |
|
1200 |
5/bag |
17.6 |
||||||||||||
| PLG03 | 3/8 | 0.41 | 0.43 | 0.31 |
700 |
5/bag |
|
700 |
5/bag |
28.7 |
||||||||||||
| PLG05 | 1/2 | 0.54 | 0.56 | 0.38 |
500 |
5/bag |
|
500 |
5/bag |
44 |
||||||||||||
| PLG07 | 3/4 | 0.55 | 0.62 | 0.44 |
300 |
5/bag |
|
300 |
5/bag |
60 |
||||||||||||
| PLG10 | 1 | 0.69 | 0.81 | 0.50 |
200 |
5/bag |
|
200 |
5/bag |
121 |
||||||||||||
| PLG12 | 1-1/4 | 0.71 | 0.93 | 0.56 |
120 |
5/bag |
|
120 |
5/bag |
181.5 |
||||||||||||
| PLG15 | 1-1/2 | 0.73 | 1.38 | 0.62 |
80 |
5/bag |
|
80 |
5/bag |
260 |
||||||||||||
| PLG20 | 2 | 0.76 | 1.31 | 0.68 |
50 |
5/bag |
|
50 |
5/bag |
357.5 |
||||||||||||
| PLG25 | 2-1/2 | 1.07 | 1.50 | 0.74 |
40 |
1/bag |
|
40 |
1/bag |
555 |
||||||||||||
| PLG30 | 3 | 1.38 | 1.68 | 0.80 |
25 |
1/bag |
|
25 |
1/bag |
920 |
||||||||||||
| PLG35 | 3-1/2 | * | * | * |
16 |
1/bag |
|
16 |
1/bag | * | ||||||||||||
| PLG40 | 4 | 1.22 | 2.25 | 0.92 |
14 |
1/bag |
|
14 |
1/bag |
1620 |
||||||||||||
|
1.Technical: Casting |
6.Material: ASTM B62,UNS Alloy C83600 ;ASTM B824 C89633 |
|
2.Brand:“ P” |
7.Fitting Dimensions: ASEM B16.15 Class125 |
|
3.Product Cap.: 50Ton/ Mon |
8.Threads Standard: NPT conform to ASME B1.20.1 |
|
4.Origin:Thailand |
9.Elongation: 20% Minimun |
|
5.Application：Jointing Water Pipe |
10.Tensile Strength:20.0kg/mm(minimum) |
|
11.Package: Exporting Stardard,Master Carton with Inner boxes Master Cartons:5 layer corrugated paper |
|
We have completely strict quality management system.
|
Every piece of fitting must be inspected under strict SOP whatever from initially raw material incoming to product processing to finished products which are 100% water test qualified before they are into our warehouse. |
1.Raw Material checking，Keeping the Incoming Material Qualified |
| 2. Molding 1).Inspecting the tem. of molten iron. 2.Chemical Composition | |
| 3.Rotary cooling:After Casting, appearance Inspection | |
| 4.Grinding Appearance checking | |
| 5.Threading In-process checking appearance and threads by Gages. | |
| 6. 100% water Pressure Tested, ensure no leakage | |
| 7.Package:QC Checked if the packed cargoes are the same with the order |
|
Mode |
Cu% |
Zn% |
Pb% |
Sn% |
|
C83600 |
84.6~85.5 |
4.7~5.3 |
4.6~5.2 |
4.7~5.1 |
Keep every pipe fitting that our Clients’ received is qualified.
Q:Are you factory or trading company?
A:We are factory with +30 years history in casting field.
Q: What terms of payment do you support?
A: TTor L/C. 30% payment in advance, and the 70%balance would be
paid before shipment.
Q: How long is your delivery time?
A: 35 days upon receipt of advanced payment.
Q: lt is possible to get samples from your factory?
A: Yes. free samples will be provided.
Q: How many years the products guaranteed?
A: Minimum 1 years.
